Test Fixture Pogo Pins, L 10.00~40.00 mm, Precision Design

Test Fixture Pogo Pins, L 10.00~40.00 mm, Flexible customization

Test Fixture Pogo Pins, L: 10.00~40.00, Best Design

Test Fixture Pogo Pins feature dual-head precision design with durable wear-resistant plating, ensuring stable electrical connections and long-term reliability. Ideal for diverse testing and connection tasks in instruments, electronics, and communication equipment. We offer custom Pogo Pins and professional service to maximize customer satisfaction and create significant value.

Product Features:

Precise contact for worry-free testing and high efficiency.
Dual-head design offers strong compatibility and flexibility.
Durable, long-lasting, reducing replacements and saving time.
High-pressure springs ensure stable conduction, reliable data.
Corrosion-resistant adapts to environments for durability.
Custom services meet needs and enhance efficiency.

Get A Free Quote

More Selection

Test Fixture Pogo Pins, L: 10.00~40.00 mm, Description

Product Info: The Double-Headed Test Fixture Pogo Pins are precision spring probes designed for high-tech testing. With their top-notch conductivity and durability, these Pogo Pins are just right for working with complicated electronic devices. The unique dual-head design significantly boosts testing efficiency and stability, becoming essential in testing processes.
Product Features: These Test Fixture Pogo Pins are made from high-quality gold-plated materials to ensure excellent conductivity and corrosion resistance. With a lifespan of up to 10,000 uses, they minimize replacement frequency, making them ideal for high-volume testing tasks.
Problem Solved: The dual-action design of these Test Fixture Pogo Pins addresses the limitations of single-headed probes, allowing for simultaneous double-sided testing. This enhancement greatly improves testing accuracy and speed, reducing equipment downtime and increasing production efficiency by 30%.
Specifications: The pins range from 10mm to 40mm in length and can be customized for travel distance. With a contact resistance of at least 15 milliohms and a spring force of at least 15gf, Test Fixture Pogo Pins meet stringent testing requirements for various electronic products, ensuring precise and efficient signal transmission.
Successful Application: In the semiconductor industry, these Test Fixture Pogo Pins have successfully been used for testing advanced IC chips, improving testing accuracy by 40% and significantly reducing rework rates. Test Fixture Pogo Pins have become the preferred testing tool for leading companies in the field.
Target Industries: These Test Fixture Pogo Pins are primarily used in electronics testing, semiconductor manufacturing, and smart hardware development, particularly in high-tech companies that demand exceptional testing accuracy and efficiency, pushing industry standards forward.
Benefits to Customers: Using Double-Headed Test Fixture Pogo Pins helps customers dramatically reduce testing time and maintenance costs while enhancing overall testing accuracy and stability. This leads to lower failure rates and increased capacity, achieving up to a 50% boost in efficiency.

Test Fixture Pogo Pins, L: 10.00~40.00 mm, Datasheet

No.#	Categories	Specification Range	Unit	Purpose	Benefits	Applications
1	Barrel OD	≥0.80, custom	mm	*	*	*
2	Plunger OD	≥0.45, custom	mm	*	*	*
3	Shape	Same OD dual heads, Different OD dual heads, custom	*	*	*	*
4	Length	7.00~9.99	mm	*	*	*
5	Stroke	≥0.55, custom	mm	*	*	*
8	Voltage Rating	≥3.0, custom	V	*	*	*
9	Current Rating	≥0.5, custom	A	*	*	*
10	Spring Force	≥30, custom	gf	*	*	*
11	1. Material	Brass	*	Stable mechanical performance, strong corrosion resistance, good electrical conductivity.	Relatively low cost, suitable for precision machining, easy to shape into complex forms.	Manufacturing precision electronic components like RF connectors and electronic contacts.
12	2. Material	Copper	*	Excellent oxidation resistance, high electrical conductivity, good thermal conductivity.	Ideal for high-frequency electronic components, enhances signal transmission stability.	RF antennas, electrical connectors in communication equipment.
13	3. Material	Stainless Steel	*	Strong corrosion resistance, high mechanical strength, heat-resistant.	Suitable for applications requiring long-term stability and durability.	High-demand fields such as medical instruments and automotive electronic connectors.
14	4. Material	Phosphor Bronze	*	Excellent electrical conductivity, superior elasticity, high wear resistance.	Suitable for environments requiring frequent connections and disconnections, excellent electrical performance.	High-frequency connectors like chip test fixtures and electronic test sockets.
15	5. Material	Nickel Alloy	*	High temperature resistance, strong corrosion resistance, stable mechanical performance.	Ideal for extreme environments like aerospace and military electronic devices.	High-reliability applications such as high-frequency communication equipment and radar receivers.
16	1. Plating	Silver Tin Plating	*	High purity, good conductivity, and corrosion resistance.	Excellent welding performance, stable electrical properties, and high temperature resistance.	Used in high-frequency connectors, RF devices, antennas, etc., to enhance signal transmission efficiency and stability.
17	2. Plating	Nickel Gold Plating	*	High hardness, wear resistance, and corrosion resistance.	Increases product lifespan, improves surface smoothness, and protects against oxidation.	Suitable for medical equipment, aerospace components, enhancing durability of connectors and contacts.
18	3. Plating	Silver Palladium Plating	*	Outstanding oxidation resistance and wear resistance.	Enhances connection stability and reliability, reduces signal transmission loss.	Used in communication equipment, industrial control systems for high-precision and stable connections.
19	4. Plating	Gold Rhodium Plating	*	High hardness, strong corrosion resistance.	Improves electrical conductivity of connectors, oxidation resistance, and high temperature resistance.	Used in high-end communication devices, military equipment for high-frequency connectors and test probes requiring high stability and long-term performance.
20	5. Plating	Tin Platinum Plating	*	Extremely low resistance, strong high temperature stability.	Suitable for high-frequency signal transmission, strong corrosion resistance, long lifespan.	Used in precision instruments, medical devices requiring extremely stable signal integrity, enhancing signal accuracy and reliability.

Get a Free Quote for Test Fixture Pogo Pins

When choose our Test Fixture Pogo Pins, you get unmatched reliability and high precision. We pride ourselves on over 98% customer satisfaction and offer a guaranteed test lifespan from 10,000 to 200,000 cycles. Boost your engineering efficiency twofold and ensure seamless production processes.

Get A Free Quote Now
